TP LINK 1350 AP CEIL/WALL DB W/MNG POE

Product Description

AC1200 Wireless Dual Band Gigabit Ceiling Mount Access Point EAP225

Simultaneous 300Mbps on 2.4GHz and 867Mbps on 5GHz totals 1200Mbps Wi-Fi speeds
Free EAP Controller Software lets administrators easily manage hundreds of EAPs
Support Power over Ethernet(802.3af) for convenient and affordable installation
Captive portal provides a convenient method for guest authentication
Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections


HARDWARE FEATURES

Interface
Gigabit Ethernet (RJ-45) Port *1(Support IEEE802.3af PoE)

Button
Reset

Power Supply
PoE or External 12VDC / 1.5A Power Supply

Power Consumption
10.15 W

Antenna Type
Internal Omni
2.4GHz: 2* 4dBi
5GHz: 2*4dBi

Mounting
Ceiling /Wall Mounting (Kits included)

Physical Security Lock
Kensington Lock Slot

Watch Dog
Yes


WIRELESS FEATURES



Wireless Standards
IEEE 802.11ac/n/g/b/a

Frequency
2.4GHz and 5GHz

Signal Rate
5GHz:Up to 867Mbps
2.4GHz:Up to 300Mbps


Wireless Functions
Multiple SSIDs(Up to 16 SSIDs, 8 for each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Band Steering
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client


Wireless Security
Captive Portal Authentication Access Control Wireless MAC Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK

Transmission Power
FCC: <27dBm(2.4GHz & 5GHz)


MANAGEMENT



EAP Controller Software
Yes

Email Alerts
Yes

LED ON/OFF Control
Yes

Management MAC Access Control
Yes

SNMP
v1,v2c

System Logging Local/Remote Syslog
Local/Remote Syslog

Telnet
Yes

Web-based Management
HTTP/HTTPS

L3 Management
Yes

Multi-site Management
Yes

Management VLAN
Yes


OTHERS



Certification
FCC, RoHS

Package Contents
AC1200 Wireless Dual Band Gigabit Access Point EAP225
Power Adapter
Mounting Kits
Installation Guide

System Requirements
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10

Environment
Operating Temperature: 0?~60? (32?~144?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
