80 PLUS GOLD CERTIFIED
The efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS Gold certification promises lower energy consumption and higher efficiency.
ATX 3.1 Ready
It has an output port that is compliant with PCIe CEM 5.1 and Intel PSDG (Power Supply Design Guide)ATX 3.1, also this power supply can hold up to 2x total power excursion and 3x GPU power excursion.
Offer the CPU sufficient power
This power supply features dual 4+4-pin PCIe power connectors, providing ample 12V power to support high-performance CPUs.
FAN
The fan curve is designed to prioritize low noise output while maintaining effective cooling. When the power supply operates at 70% load, the resulting noise level is kept below 20 dBA.
Capacitors You Can Trust
The 105°C main capacitor is designed to perform reliably in handling high temperatures and peak voltage fluctuations. It ensures stable performance, providing your system with dependable reliability.
CERTIFIED CABLE
This power supply comes equipped with certified cables and connector made of copper alloy terminals. This provides greater safety than typical phosphor bronze connectors, especially during high current surges.
|
| Modular |
No (non modular) |
|
| Fan Bearing |
Sleeve Bearing |
|
| Power Watt |
750W |
|
| Input Voltage Range |
100~240 VAC |
|
| Power Excursion |
1500W (*up to 200% of the PSU's rated power for 100µs) |
|
| Input Frequency |
47-63Hz |
|
| ATX (24 pin) |
1 |
|
| Efficiency |
80 PLUS Gold (up to 90%) |
|
| EPS (4+4 PIN) |
2 |
|
| PCI-E 5.1 (16 pin) |
1 |
|
| Fan Size |
120 mm |
|
| Dimension |
140 x 150 x 86 mm |
|
| PCI-E (6+2 pin) |
2 |
|
| PFC Type |
Active PFC |
|
| SATA (15 pin) |
4 |
|
| Protection |
OCP / OVP / OPP / OTP / SCP |
|
| MOLEX (4 pin) |
2 |
|
| UPC |
0824142374801 |
