Mnhtn USB 3.0  2 Port PCI-Ex1
Mnhtn USB 3.0 2 Port PCI-Ex1
Item #
CCU3NEMN02
Brand
Manhattan
Model
151375

Warranty
Lifetime
Condition
Retail Box
If out of stock
3 to 5 Days
Product Description

Create a computing platform that balances cost, performance and compatibility.

Computers today can take full advantage of SuperSpeed USB and PCI Express efficiency with the MANHATTAN SuperSpeed USB PCI Express Card. Easily installed, the MANHATTAN SuperSpeed USB PCI Express Card provides up to 500 mA of power and adds 2 external SuperSpeed USB ports to a desktop PC for more USB devices and improved convenience. With SuperSpeed USB data transfer rates of up to 5 Gbps and hot-swap capability, the MANHATTAN SuperSpeed USB PCI Express Card fits PCI Express x1, x2, x4, x8 and x16 lane buses to ensure that connected SuperSpeed USB and other USB peripherals operate at peak performance.


Features:

Easily adds two SuperSpeed USB ports to desktop computers

Each port supports USB 3.0 data transfer rates of up to 5 Gbps

Fits PCI Express x1, x2, x4, x8 and x16 lane buses

4-pin power connector for receiving extra power from system

Plug and Play installation; hot-swappable — Windows compatible

Lifetime Warranty


Specifications:

Standards and Certifications

USB 3.0

CE

FCC

ExpressCard Specification 2.0

RoHS

WEEE


Port Specifications

Up to 900 mA power to attached devices

(2) USB 3.0 Standard-A ports

Data transfer rate: Up to 5 Gbps

NEC USB controller


Bus Specifications

PCI Express x1

Bus speed 5 Gbps

Fully compliant with ExpressCard Specfication 2.0


Physical

Dimensions: 12.1 x 2.3 x 10 cm (4.75 x 0.9 x 3.9 in.)

Weight: 59.5 g (2.1 oz.)


System Requirements

Windows XP/Vista/7 32- and 64-bit

PCI Express-enabled system with an available PCI Express slot

Must have an available 4pin molex on the power supply to work correctly


Package Contents

SuperSpeed USB PCI Express Card, x1 lane

User manual, low profile bracket and CD driver
