Multitask with confidence
The ThinkCentre M80s’ small form factor desktop handles it all, with up to Intel vPro® Enterprise with 12th Generation Intel® Core™ i9 processors and time-saving features like Smart Power On and a front-panel USB-C port. Connect up to four displays and multiple compatible devices to configure your workspace. Plus, with an optional AMD Radeon RX6400, you can power through hi-res renderings, video editing, and VR/AR content with ease. Additionally, ICE 5.0 Cooling (Intelligent Cooling Engine) ensures your ThinkCentre maintains temperatures at an optimal level for high-performance computing while carefully controlling power consumption.
Security inside and out
Get end-to-end security with Lenovo’s comprehensive ThinkShield solution, featuring dTPM 2.0 and Smart USB protection. The Intel vPro® platform combines the best of Intel innovations, so you can accelerate business productivity, better safeguard data and assets, and ensure long-term stability. This desktop PC can even self-heal if it becomes corrupted and has several physical security options to thwart theft.
Expands with your business
With ample I/O ports, optional WiFi 6E, and added expansion slots, the ThinkCentre M80s Gen 3 grows along with your business thanks to the toolless access design. Add graphics cards to support industry-specific imaging equipment, connect to legacy peripherals, and configure things your way to discover countless productive possibilities. You can also opt for dual solid-state drives (SSD) storage for improved responsiveness and power consumption, as well as faster boot ups and application launches. *WiFi 6E requires Windows 11 Pro. Operation is dependent on the support of the operating system, routers/APs/gateways that support WiFi 6E, along with the regional regulatory certifications and spectrum allocation.
Small form factor desktop meets ultra-responsive powerhouse
Intel vPro® Enterprise with 12th Gen Intel® Core™ processors for A1 performance
Able to bridge between legacy peripherals & future workspace needs.
Built-in security, durability. & reliability
Supports lightning-fast Intel® WiFi 6E & dual SSD storage
Made & packaged from recycled materials, certified energy-efficient
|
Processor
|
12th Generation Intel® Core™ i5-12500 Processor with vPro® (P-Core Max 4.60 GHz with Turbo Boost, 6 Cores, 12 Threads, 18 MB Cache)
|
|
| Operating System |
Windows 11 Pro
|
|
Memory
|
8 GB DDR5 UDIMM 4400MHz
|
|
Storage
|
256 GB M.2 PCIe SSD
|
|
| Graphics |
Integrated Intel® UHD Graphics 770
|
|
Security
|
Discrete Trusted Platform Module (dTPM) 2.0 chip
EC Self-healing (level 2)
BIOS-based Smart USB Protection
Optional: Chassis E-lock
Kensington Security Slot™
Optional: Padlock loop
Optional: Smart cable clip
|
|
| Dimensions (H x W x D) |
339.5mm x 92.5mm x 297.7mm / 13.4" x 3.6" x 11.7"
|
|
| Weight |
Starting at 5.3kg / 11.7lbs
|
|
Color
|
Raven Black
|
|
| Ports / Slots |
Front:
USB-C 3.2 Gen 2 (15W Charging)
2 x USB-A 3.2 Gen 2
2 x USB-A 3.2 Gen 1
Optional: 3-in-1 card reader
Headphone / mic combo
Mic
Rear:
4 x USB-A 3.2 Gen 1
Optional: Flex I/O (DP / HDMI / Type-C / VGA)
HDMI 2.1 TMDS
2 x DisplayPort 1.4
LAN (1G)
Headphone
Optional: 4 x Serial
Optional: PS2
Optional: Parallel
Optional: USB-A 2.0
USB port transfer speeds are approximate and depend on many factors, such as processing capability of host/peripheral devices, file attributes, system configuration and operating environments; actual speeds will vary and may be less than expected.
|
|
| M.2 Slots |
2 x M.2 SSD Gen 4
M.2 WiFi
|
|
| Expansion Slots |
PCIe x16 Gen 4
PCIe x16 (x4 link)
PCIe x1
|
|
| Internal Bay |
3.5" HDD
2.5" HDD
|
|
| External Bay |
Optional slim optical disc drive
|
|
| Green Certifications |
ENERGY STAR® 8.0
Up to EPEAT™ Gold*
RoHS
ERP LOT3
TÜV Low Noise
TCO 9.0*
* Varies by configurations
|
|
| Power Supply Unit (PSU) |
310W, 92%
260W, 90%
|
|
| What’s in the box |
ThinkCentre M80s Gen 3 SFF
USB Keyboard
USB Mouse
Quick Start Guide
|
