Intel Xeon E-2374G 4C 3.7GHz LGA-1200

Product Description

Intel® Xeon® E Processors Keep Small Businesses Running
Make sure your business data is accessible and protected with a professional grade server. Watch the video to learn how an entry server can power a range of business applications and provide the agility to respond to customers quickly while supporting enhanced security.

CPU Specifications	Total Cores 4 Total Threads 8 Max Turbo Frequency 5.00 GHz Intel® Turbo Boost Technology 2.0 Frequency 5.00 GHz Processor Base Frequency 3.70 GHz Cache 8 MB Intel® Smart Cache Bus Speed 8 GT/s TDP 80 W
Supplemental Information	Marketing StatusLaunched Launch Date Q3'21 Embedded Options Available No
Memory Specifications	Max Memory Size (dependent on memory type) 128 GB Memory Types DDR4-3200 Max # of Memory Channels 2 Intel® Optane™ Persistent Memory Supported No ECC Memory Supported  Yes
Processor Graphics	Processor Graphics  Intel® UHD Graphics P750 Graphics Base Frequency 350 MHz Graphics Max Dynamic Frequency 1.30 GHz Graphics Video Max Memory 64 GB Execution Units 32 4K Support Yes, at 60Hz Max Resolution (HDMI) 4096 x 2160 @60 Hz Max Resolution (DP) 5120 x 3200 @ 60 Hz Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 @ 60 Hz DirectX* Support 12.1 OpenGL* Support 4.5 Intel® Quick Sync Video Yes Intel® InTru™ 3D Technology Yes Intel® Clear Video HD Technology Yes Intel® Clear Video Technology Yes # of Displays Supported 1 Device ID0x4C9A
Expansion Options	Scalability1S Only PCI Express Revision 4.0 Microprocessor PCIe Revision Gen 4 PCI Express Configurations  Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 Max # of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1200 Max CPU Configuration1 TJUNCTION 100 °C Package Size37.5 mm x 37.5 mm
Advanced Technologies	Intel® Turbo Boost Technology  2.0 Intel® Hyper-Threading Technology  Yes Intel® Transactional Synchronization Extensions No Intel® 64  Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes
Security & Reliability	Intel vPro® Eligibility  Intel vPro® Platform Intel® AES New Instructions Yes Secure Key Yes Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® SPS Maximum Enclave Page Cache (EPC) Size for Intel® SGX0.5 GB Intel® Memory Protection Extensions (Intel® MPX) Yes Intel® OS GuardYes Intel® Trusted Execution Technology  Yes Execute Disable Bit  Yes Intel® Boot Guard Yes Intel® Virtualization Technology (VT-x)  Yes Intel® Virtualization Technology for Directed I/O (VT-d)  Yes Intel® VT-x with Extended Page Tables (EPT)  Yes
