Intel Core i9-13900K 3 GHz 24-Core LGA 1700 Processor. This 13th generation desktop processor builds upon the Hybrid Core architecture and Intel 7 process by fitting 24 cores— eight more than the previous generation— onto a single processor while still fitting the
LGA 1700 socket. Designed to provide exceptional performance, the Core i9-13900K features 16 low-voltage Efficient-cores that handle background tasks for multitasking while the eight 3 GHz Performance-cores provide speed for demanding applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.
With 32MB of cache and a 5.7 GHz Turbo Boost Max 3.0 frequency that can be pushed higher with Thermal Velocity Boost and Adaptive Boost technologies, this processor is made to handle almost any workload. You can overclock this processor for even greater performance. The Core i9-13900K also supports PCI Express 5.0 and dual-channel DDR5 ECC memory at 5600 MHz.
The Core i9-13900K features integrated Intel UHD 770 Graphics. Please note that a thermal solution NOT is included. This processor is backed by a 3-year warranty.
Hybrid Core DesignPerformance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor's Efficient-cores for multitasking.
Intel Thread DirectorThe Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 32 threads are assigned to the right core at the right time.
PCIe 4.0 & 5.0This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Thermal Velocity BoostIntel Thermal Velocity Boost (TVB) is a technology that unlocks extra CPU performance by pushing the maximum frequency to 5.8 GHz when thermal headroom and turbo power budget are available. It is ideal for burst workloads that have sudden spikes in CPU utilization, providing a temporary performance boost to help avoid slowdowns.
Adaptive BoostIntel Adaptive Boost Technology opportunistically increases the all-core turbo frequency beyond previous Turbo Boost clock speeds, even when Thermal Velocity Boost conditions aren't met. Benefits can be seen with multi-threaded programs that scale with multiple cores, which includes many games. It can also help in multitasking situations, such as when gaming, streaming, and chatting all at once through different applications.
Integrated GraphicsDriven by Intel Xe architecture, the integrated Intel UHD 770 Graphics delivers fast, rich 3D performance for high-quality visuals with support for either one 7680 x 4320 resolution 8K monitor or up to four 3840 x 2160 resolution 4K displays with high-dynamic range.
Intel Deep Learning BoostAccelerates AI inference to improve performance for deep learning workloads.
Gaussian & Neural Accelerator 3.0Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
|
General
|
CPU Model Intel Core i9-13900K (13th Gen) CPU Socket LGA 1700 Manufacturing Process 10 nm Maximum CPU Configuration 1S Maximum Number of PCIe Lanes 16 (Revision 5.0) 4 (Revision 4.0) Unlocked Yes
|
|
Performance |
Number of Cores 24 (8 x P-Cores + 16 x E-Cores) Number of Threads 32 Base Clock Speed P-Core: 3 GHz E-Core: 2.2 GHz Maximum Boost Speed P-Core Turbo: 5.4 GHz E-Core Turbo: 4.3 GHz L3 Cache 36 MB
|
|
Memory Support
|
Maximum Capacity 128 GB Memory Support DDR5 5600 MHz DDR4 3200 MHz ECC Memory Yes Channel Architecture Dual Channel Optane Memory Support Yes
|
|
Power
|
Thermal Design Power (TDP) 125 W Included Thermal Solution None Maximum Temperature 212°F / 100°C Thermal Monitoring Technologies Yes
|
|
Technology |
AES Support Yes Extension AVX 2.0, AVX-512, SSE 4.1/4.2 Instruction Set 64-Bit Virtualization Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT) vPro Support Yes Performance Technologies Adaptive Boost, Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Stable Image Platform Program, Thermal Velocity Boost, Turbo Boost 2.0, Turbo Boost Max 3.0 Security Technologies Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology Video Technologies Clear Video, Clear Video HD, InTru 3D, Quick Sync Video
|
|
Integrated Graphics
|
Integrated Graphics Intel UHD Graphics 770 Maximum Resolution Support 7680 x 4320 at 60 Hz Supported APIs DirectX: 12 OpenGL: 4.5 Number of Displays 4 Output Support DisplayPort, HDMI Base Clock Speed 300 MHz Maximum Boost Speed 1.45 GHz
|
