EVGA 100-BA-0600-K1 600WT 80+ Bronze Power Supply
The EVGA BA Power Supplies are here to add that final luster to your PC without leaving a hole in your wallet. Certified 80PLUS™ Bronze, BA power supplies utilize a DC-DC converter to make sure value does not come at the expense of efficiency. Powered by a single +12V rail, EVGA BA power supplies are burnished with a full suite of protections and all the cables you need to build a modern gaming PC.
FEATURES
80 PLUS Bronze certified, with 85% efficiency or higher under typical loads
Single 12V. Rail
Active Power Factor Correction
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
3 Year Warranty
DC-DC Converter improves 3.3V/5V stability
Quiet and Intelligent Auto Fan for near-silent operation
CABLE LENGTH
|
ATX Cable
EPS Cable
PCIe Cable
SATA Cable
Four-Pin Peripheral Cable
AC Power
Modular Cable Type
|
1x 600mm
2x 700mm
1x 700mm , 3x 700mm, 850mm
3x 550mm, 650mm, 750mm
1x 550mm, 650mm, 750mm
1x 1500mm
Full
|
CONNECTOR QUANTITY
|
24 Pin ATX
EPS (CPU)
PCIe
SATA
Four-Pin Peripheral
Floppy
|
1x
2x 8pin(4+4)
7x 8pin(6+2)
9x
3x
1x
|
INPUT
|
Input Voltage
AC Input
Input Frequency Range
Efficiency
|
100-240V~
10-5A
60/50Hz
90% or Higher Typical
|
OUTPUT
|
Rail
Max output
Total
|
+3.3V +5V +12V -12V +5Vsb
20A 20A 70.8A 0.3A 3A
130W 850W 3.6W 15W
850W
|
ADDITIONAL DETAILS
|
Japanese Capacitors
ECO Mode
MTBF
Net Weight
Size
Approvals
Fan Size / Bearing
UPC
|
100%
Auto
100,000 Hours
6 lbs
86mm (H) x 150mm (W) x 150mm (L)
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 3 2014 Requirement
135mm Fluid Dynamic Bearing
843368068080
|
