ADA 8805 8 port SAS RAID Cont 12Gb
ADA 8805 8 port SAS RAID Cont 12Gb
Item #
CC6805SAE
Brand
Adaptec
Model
2294001-R

Warranty
3 Year
Condition
Retail Box
If out of stock
5 to 7 Days
Product Description

The Series 8E entry-level 12 Gbps PCIe Gen3 SAS/SATA RAID adapters deliver the robustness of hardware RAID in an entry-level solution. They offer performance acceleration through built-in cache and are optimized for platforms where a Series 8 adapter would not fit due to price, form factor, or host connectivity. The 8805E, with eight internal SAS/SATA ports, is ideal for applications that require more bandwidth. Both models fit the requirements of industrial PC workstations or entry-level servers. The 8405E and the 8805E support a maximum of four and eight devices respectively, as neither support expanders.

Maximum Performance for Entry-Level RAID Adapters
Series 8E RAID adapters can also be coupled with 12 Gbps SSDs, providing maximum read/write bandwidth and IOPS for the most performance-hungry applications. The 512 MB DDR3 (1600 MHz) built-in cache (recommended for read and write-through caching) provides maximum acceleration.

RAID Levels: 0
  10
Controller Type: 12Gb/s SAS
Product Type: SAS Controller
SAS Connector Details: 2 SFF-8643
Brand Name: Microsemi Adaptec
Total Number of SAS Ports: 8
RAID Levels: 1
Form Factor: Plug-in Card
Host Interface: PCI Express 3.0 x8
RAID Supported: Yes
General Information
Brand Name: Microsemi Adaptec
Manufacturer Part Number: 2294001-R
Product Name: 8805E SAS Controller
Manufacturer Website Address: http://www.microsemi.com
Product Model: 8805E
Manufacturer: Microsemi Corporation
Product Series: 8E
Product Type: SAS Controller
Technical Information
RAID Levels: 0
  1
Host Interface: PCI Express 3.0 x8
RAID Levels: 10
RAID Supported: Yes
Controller Type: 12Gb/s SAS
Interfaces/Ports
SAS Connector Details: 2 SFF-8643
Total Number of SAS Ports: 8
Physical Characteristics
Width: 6.6"
Height: 2.5"
Form Factor: Plug-in Card
Memory
Cache Memory: 512 MB
Warranty
Limited Warranty: 3 Year
Miscellaneous
Environmentally Friendly: Yes
Platform Supported: PC
Environmental Certification: RoHS
