Image Sensor:
|
1/1.8” 8.0 MegaPixel (4K) Progressive Scan CMOS
|
|
| Image Size: |
8 MegaPixel (3840 × 2160)
|
|
Resolution:
|
8MP (3840×2160), 6MP(3072×2048), 5MP(2592×1944), 4MP(2592×1520), 2K (2560×1440), 3MP (2304×1296), 1080P(1920 ×1080), 720P(1280×720), D1, VGA(640×480), CIF, 480 × 240
|
|
Frame Rate:
|
30fps @ 8MP (4K) and Lower (50Hz: 1~25fps)
|
|
| Main-Stream: |
8MP/6MP/5MP/4MP/2K/3MP/1080P/720P
|
|
Sub-Stream:
|
1080P/720P/D1/VGA/CIF
|
|
| Third-Stream: |
D1/VGA/CIF/480×240
|
|
| Lens: |
2.8~12mm Motorized AutoFocus Varifocal Lens
|
|
Field of View:
|
Horizontal: 113°46°, Vertical, 59°26°; Diagonal: 136°~54°
|
|
| Day/Night and Night Vision: |
Min. Illumination: 0.008lux @ F1.6 with AGC ON, 0 lux with IR, 0 lux with LED
Day/Night: True Day/Night by ICR
Night Vision/Range: White Light or Matrix IR / Up to 165’
|
|
| Video and Audio: |
Video Compression: H.265+, H.265, H.264+, H.264, MJPEG [Triple Streaming]
Audio Compression: G.711A, G.711U
Audio: 1Ch. Audio Input, 1Ch. Audio Output + Built-in Speaker + Built-in Microphone*
Alarm: 1Ch. Alarm Input, 1Ch. Alarm Output
CVBS Video Out: Yes (BNC × 1)
Bit Rate / Type: 64 Kbps ~ 12 Mbps / VBR, CBR
|
|
Advanced Features:
|
Wide Dynamic Range: 120dB Super WDR
Other Features: Highlight Compensation, Backlight Compensation, DeFog, Hardware Reset, Digital Noise Reduction XD-DNR (3D-DNR & 2D-DNR), Image Setting (ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Range Sharpness, Image Flip, Image Mirror, Noise Reduction)
|
|
Analytics
|
Advanced Analytics: Intrusion Detection, Line Crossing, Target Counting [All by Human / Motor Vehicle Classification], Face Detection, Scene Change, Video Blur, Abnormal Color Detection, Heat Map
|
|
| Alarms: |
Smart Alarm: Motion Detection, Sensor Alarm, SD Card Error, SD Card Full, IP Address Conflict, Cable Connection
Region of Interest (ROI): Each ROI to be Configured Separately |
|
| Storage |
Local Storage: Built-in MicroSD Card Slot (up to 256GB)
|
|
| Viewing: |
Remote Viewing: VMS / Web Browser / Mobile (iOS/Android)
Online Connection: Supports Simultaneous Monitoring for up to 10 Users, Support multi-stream real-time transmission
|
|
| Network and Connectivity: |
Supported Browsers: IE or Edge in IE mode, Chrome, Firefox
Network Connection: RJ45 10M/100M Self-Adaptive Ethernet port
Network Protocols: UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, RTMP, HTTP, 802.1x, UPnP, HTTPS, HTTP POST, QoS
Connection Protocol: VITEK/ONVIF
|
|
| Environmental Specifications: |
Ingress Protection: IP66
Working Environment: -22° 140°F (-30°60°C) / < 95% Humidity
Storage Environment: -22° 149°F (-30°65°C) / < 95% Humidity
|
|
Power
|
Power Input: 12VDC / PoE
Power Consumption (PoE): <14W
Power Consumption (12VDC): 600mA (LEDs Off) / 1200mA (LEDs On)
|
|
| Weight: |
Weight Net (Gross): 23.99oz / 1.50lb / 1040g (29.27oz / 1.83lb / 1200g)
Dimensions L × W × H: 10.96 × 3.95 × 3.49” (278.3 × 100.2× 88.7mm)
|
|
| Certificates |
Certificates: CE, FCC — Complies with Directive EU RoHS, WEEE(2012/19/EU), Directive 94/62/EC and REACH(EC1907/2006)
|
|
| Security: |
Security: Video Encryption, Firmware Encryption, HTTPs Encryption, Configuration Encryption, Illegal Login Lock, IP Address Filtering, 802.1x Authentication, Basic and Digest Authentication for HTTP/HTTPs
|
|
| Miscellaneous: |
DORI (W/T): Detect, Observe, Recognize, Identify distances provided
Sound/Light Warning: Flashing White Lights (Red and Blue) + Speaker with User-Defined Warning Voice Import
|
|
*Note:
|
Please research local, state, and federal law regarding the implementation and use of audio surveillance.
|
