Image Sensor
|
2 × 1/2.5” Progressive Scan CMOS Sensor
|
|
| Max Resolution |
4096 × 1800 (Stitching Mode)
|
|
Mini. Illumination
|
Color: 0.005Lux @ (f1.1, IRE 50), B/W: 0.0005 Lux@ (f1.1, IRE 50), 0 Lux with White LED
|
|
Image Setting
|
Saturation, Brightness, Contrast, Sharpness, Auto Gain Control, etc. Adjusted by Client
|
|
| Shutter Speed |
60Hz: 1/30s-1/30,000s, 50Hz: 1/25s – 1/25,000s
|
|
White Balance
|
Auto / Manual / Indoor / Outdoor
|
|
| Gain / Iris Control |
Auto / Manual
|
|
| Day & Night |
Auto / Manual, time schedule
|
|
SNR
|
=52dB
|
|
| 3D DNR |
Auto / Manual
|
|
| AE Enhancement |
Backlight Control (BLC), Highlight Control (HLC), Digital Wide Dynamic Range (D-WDR)
|
|
| Digital Zoom |
8x
|
|
| WDR |
Digital Wide Dynamic Range (D-WDR)
|
|
| Privacy Mask |
Eight (8) Areas — Up to Eight Masks in the Same Frame
|
|
| Picture Overlay |
Logo Picture Can be Overlaid on Video with 128px × 128px, 24bits JPG format
|
|
| OSD Overlay |
Max Fifteen (15) Characters / Line, Eight Lines, White or Red Colored Font
|
|
| Angle Adjustment |
Vertical -5~+5°, Rotation ±75°
|
|
| Focus Type |
2 × f=3.5mm, M12 mount, Optical Distortion <15%
|
|
| Aperture |
Fixed, f1.11
|
|
| IR CUT Type |
Fixed, White Light Pass (Only)
|
|
| D.O.R.I. |
Detect: 295’(63.65m), Observe: 117’ (25.26m), Recognize: 39’ (12.73m), Identify: 29.5’ (6.36m)
|
|
| IR Type / Range |
Warm White Light 65' (20m)
|
|
| Smart Brightness |
Yes – Facial Priority
|
|
| stream |
Mainstream A.I. On
60Hz: 20fps – 4096 × 1800 (4K), 3840 × 1680, 2880 × 1264, 1920 × 1080, 1280 × 720, 50Hz: 20fps – 4096 × 1800 (4K), 3840 × 1680,2880 × 1264,1920 × 1080,1280 × 720
Sub stream A.I. On
60Hz: 20fps – 1920 × 1080, 1280 × 720, 704 × 480, 640 × 240, 50Hz: 25fps: 704 × 576, 640 × 240, 480 × 240
3rd Stream A.I. On
60Hz: 30fps – 704 × 480, 640 × 240, 480 × 240, 50Hz: 20fps – 1920 × 1080, 1280 × 720, 704 × 576, 640 × 240
|
|
| Video |
Video Compression
Smart H.265+/H.265/H.264+/H.264/MJPEG
H.264 Standard
H.264 / AVC codec BP / MP / HP, Level 5.1
H.265 Standard
H.265 / HEVC codec MP, level 5.0
Video Bit Rate
64 Kbps to 16Mbps
|
|
| Microphone |
One Built-in Mic, Omni-Directional, 2KO, -36dB@1KHz Sensitivity, THD 115dB SPL@1KHz*
|
|
| Speaker |
One Built-in speaker, 4O, 2W Nom, 750Hz LFR, 100dB@0.1m
|
|
| AUDIO |
Audio Compression
64 Kbps to 16Mbps
Audio Compression
G.711 A/U
Audio Bit Rate
64 Kbps
|
|
| Protocols |
HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE, P2P, SSL/TLS
|
|
| User / Host |
Up to Sixteen Users, Three Levels: Administrator, Advanced User and Normal User
|
|
| API |
ONVIF G/S/T, Support VITEK SDK and Third-Party Management Platform
|
|
| Event |
Basic Event
Motion Detection, Video Tampering Alarm, Alarm Input, Alarm Output, Exception (Network Disconnection, IP Address Conflict, SD Card Full, SD Error)
Smart Event
Line Crossing, Region Entrance / Exit Detection, Object Removal Detection, Intrusion Detection
Alarm Linkage
Alarm, Memory Card Record, Trigger Record, Notify Surveillance Center, Upload to FTP/Memory Card, Send Email
Face Capture
Detect Multiple Faces in the Same Scene – Supports Detection, Capture, Grading, and Output
Face Comparison
Yes (Default Off)
Perimeter Protection
Line Crossing, Intrusion, Region Entrance, Region Exit, Support Alarm Triggering by Specified Type
|
|
| Alerm |
Alarm Interface
1 Alarm Input (Dry Contact), 1 Alarm Output
Alarm Linkage
Upload to FTP/Memory Card, Notify Surveillance Center, Send Email, Trigger Alarm Output / Recording / Capture
|
|
| Ports |
Aux. Audio Interface
1Ch. LINE IN, 2.0-2.4Vpp, Impedance 1KO, 1Ch. LINE OUT, Impedance 600O*
Network Interface
1 RJ45 10M/100M Adaptive Ethernet
SD Card Slot
MicroSD Slot and Chamber, up to 256G
Reset Button
Yes
|
|
| Power Supply |
DC12V±15% 1500mA (Or) PoE+ (802.3.af, Class 3)
|
|
| Housing Material |
Main Body: Aluminum Alloy (ADC12), Lens Cover: Polycarbonate
Working Conditions
-40°C~55°C (-40°F ~ 131°F), Cold start>=-30°C (1 hour waiting);90%RH
Storage Condition
-40°C ~ 70°C; = 95% RH
|
