| Image Sensor |
1 / 2.5” CMOS |
|
| Image Size |
3200×1800 |
|
Electronic Shutter
|
1 / 4s ~ 1 / 100000s |
|
| Lens |
2.8~12mm Motorized Varifocal |
|
| Min. Illumination |
0.008 lux @F1.6, AGC On, 0 lux with illumination on |
|
| Field of View |
Horizontal 108°~36°, Vertical: 57°~20°, Diagonal: 129°~42° |
|
| Focus |
Motorized AutoFocus |
|
Supplemental Light Range
|
IR range: up to 165’, White light range: up to 130’ |
|
| Day & Night |
ICR |
|
| Wide Dynamic Range |
120dB |
|
BLC
|
Yes – Backlight Control |
|
| HLC |
Yes – Highlight Control |
|
| Digital Noise Reduction |
Yes – DNR |
|
S/N Ratio
|
=50dB |
|
Angle Adjustment
|
Pan: 0°~360°, Tilt:0°~80°, Rotation: 0°~360° |
|
| Video Compression |
Main stream: H.265+ / H.265 / H.264+ / H.264, Sub /Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|
| H.265 Standard |
Main Profile@Leve4.1 High Tier |
|
Resolution
|
6MP(3200×1800), 4MP(2688×1520), 1080P(1920×1080 ), 720P(1280×720), D1, VGA(640×480), 480×240, CIF |
|
Main Stream
|
60Hz: 6MP(1~20fps) /4MP/1080P (1~30fps) 50Hz: 6MP(1~20fps) /4MP/1080P (1~25fps) |
|
Sub Stream
|
720P/D1/VGA/CIF (60Hz: 1~30fps; 50Hz: 1~25fps) |
|
| Third Stream |
D1/480× 240/CIF (60Hz: 1~30fps; 50Hz: 1~25fps) |
|
| Bit Rate |
64 Kbps ~8Mbps |
|
| Bit Rate Type |
VBR / CBR |
|
| Image Settings |
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser |
|
| Audio Compression |
G711A/U |
|
| ROI |
Each ROI to be configured separately |
|
| Security Video encryption |
Video encryption, firmware encryption, HTTPS encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP/RTSP
D.O.R.I. 2.8~12mm(W) Detect: 218ft(66m) Observe: 87ft(27m) Recognize: 44ft(13m) Identify: 23ft(7m) 2.8~12mm(T) Detect: 669ft(204m) Observe: 269ft(82m) Recognize: 135ft(41m) Identify: 66ft(20m)
|
|
| Ingress Protection |
IP67 Weather Resistance |
|
| Audio |
1CH audio input, 1CH built-in MIC* |
|
Storage
|
Built-in micro SD card slot (up to 256GB) |
|
| Reset |
Yes |
|
Remote Monitoring
|
Web browser / Transcendent NVR / VMS / Mobile App
|
|
| PoE |
Yes (IEEE802.3af) |
|
| Online Connection |
Web Browser Chrome 89.0+ / Edge 89.0+ / Firefox 87.0+ / Safari 14.0+
Online Connection Support simultaneous monitoring for up to 6 users, Support multi-stream real time transmission
Network Protocol UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, P2P, QoS
Interface Protocol ONVIF |
|
| Network Protocol |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, P2P, QoS |
|
| Smart Alarm |
Motion detection, SMD, SD card error, SD card full, IP address conflict, network disconnection, video exception
Programmable Analytics Line crossing / Region Intrusion Detection (by human / vehicle classification), Object Abandoned / Missing, Scene Change Detection, Video Blur, Video Color Cast Detection
More Features Watermark, IP address filtering, video mask, heartbeat, ANR, cloud upgrade, smart supplement light, corridor pattern |
