Key Features
Multimedia SoC CPU
Removable IR cut filter enables day and night functionality
Supreme Night Visibility (SNV) for low-light conditions
Smart IR technology
H.265, H.264, and MJPEG video codecs
Three simultaneous streams
Smart Stream III optimizes bandwidth efficiency
Seamless recording
Fixed iris
48x digital zoom
Camera pivots 350° horizontally and 75° vertically
350° rotation range
WDR Pro (120 dB)
67 dB S/N ratio
Image settings include time stamp, text overlay, flip & mirror, configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, scheduled profile settings, highlight compensation, defog, 3D-DNR, and video rotation
Five-window video motion detection
Alarm triggers include motion detection, periodical trigger, system boot, recording notification, camera tampering detection, manual trigger, microSD card life expectancy, and cybersecurity (brute force attack event, cyberattack event, quarantine event)
Event notification via email, HTTP, FTP, NAS server, and microSD card
File upload via email, HTTP, FTP, NAS server, and microSD card
100M Ethernet
System power and status LED indicators
Live viewing for up to ten clients
Compatible with Microsoft Windows 7 and 8, Mac 10.12 (Chrome only), Chrome 58.0 or above, Internet Explorer 10 and 11, VLC 1.1.11 or above, QuickTime 7 or above, VADP (Trend Micro IoT Security, Stratocast), VAST VMS, and Shepherd camera management tool
CE, FCC Class B, UL, LVD, VCCI, and C-Tick certified
|
| Camera |
Sensor
5 MP 1/2.7" CMOS
Focal Length
3.6mm
Maximum Aperture
f/2
Zoom
Digital: 48x
Lens Field of View
Horizontal: 76°
Vertical: 59°
Diagonal: 100°
IR Cut Filter
Mechanical
Day/Night
Yes
Minimum Illumination
Color: 0.03 Lux
B&W: 0 Lux
Shutter Speed
1/32000 to 1/5 Seconds
Camera Angle Adjustment
Horizontal: 0 to 350°
Vertical: 0 to 75°
|
|
| Video |
Streaming Resolution
2560 x 1920 at 20 fps
Supported Video Compression
H.264, H.265, MJPEG
Multi-View Streaming
Yes, 3 Streams
|
|
Audio
|
Built-In Mic
No
|
|
Pan & Tilt
|
None
|
|
| Networking |
Security
HTTPS, IEEE 802.1X
Supported Protocols
ARP, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, PPPoE, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP
|
|
System Integration
|
Application Programming Interface (API)
ONVIF Profiles G & S
Analytics
Five-Window Video Motion Detection
OS Compatibility
Windows 7
Windows 8
macOS 10.12
*As of March, 2020: Check with manufacturer for the most up-to-date compatibility
|
|
| Sensors & Alarms |
Event Trigger
Yes
Event Action
Recording, Notification, Alarm
Data Streaming
Yes
|
|
| Hardware |
Memory
512 MB RAM / 128 MB Flash
Media/Memory Card Slot
Single Slot: microSD/microSDHC/microSDXC [64 GB Maximum]
External Storage Options
NAS
|
|
Power
|
Power Source
PoE 802.3af (15 W)
Power Consumption
6.49 W
|
|
| Environmental |
Operating Temperature
-22 to 140°F / -30 to 60°C
Startup Temperature
14 to 140°F / -10 to 60°C
Operating Humidity
90%
IP Rating
IP66
IK Rating
IK10
|
|
| General |
Inputs/Outputs
1 x RJ45
Illumination
IR LEDs up to 98.4' / 30 m
Video Management Software
VAST, Shepherd
Supported Languages
English
French
German
Italian
Japanese
Portuguese
Simplified Chinese
Spanish
Traditional Chinese
Dimensions
ø: 4.6 x H: 3.5" / ø: 117.2 x H: 89.6 mm
Weight
1.19 lb / 540 g
|
|
| Packaging Info |
Package Weight
1.8 lb
Box Dimensions (LxWxH)
7.3 x 7 x 6"
|
