| Image Sensor |
1/2.7” 5.0 Megapixel CMOS Image Sensor |
|
| Image Size |
5 MegaPixel (2880 × 1620) |
|
Resolution
|
Up to 20fps@5MP (2880 × 1620), Up to 30fps@4MP (2560 × 1440), 3MP (2304 × 1296), 1080P (1920 × 1080), 720P (1280 × 720), D1, 480× 240, CIF |
|
| Min. Illumination |
0.007 lux @F1.6, AGC ON; 0 lux with IR |
|
| Electronic Shutter |
1 s ~ 1 / 100000 s |
|
| Lens |
2.8~12mm Motorized Varifocal Lens, FoV H: 110.5°, FoV V: 57°, FoV Diag: 131° |
|
| IR LEDs (Range) |
2 Matrix Style IR (up to 165’) |
|
| Video Compression |
H.265+ / H. 265 / H.264+ / H.264 / MJPEG |
|
Audio Compression
|
G.711A / G.711U |
|
| Main-Stream |
5MP(1~20fps)/4MP/3MP/1080P/720P(1~30fps) |
|
| Sub, Third Stream |
720P/D1/ CIF (1~30fps), 60Hz: D1/480× 240/CIF (1~30fps) |
|
Bit Rate / Type
|
64 Kbps ~ 8 Mbps / VBR + CBR |
|
Wide Dynamic Range
|
120dB WDR |
|
| Digital Noise Reduction |
3D-DNR |
|
Other Features
|
Back Light Compensation, Highlight Compensation |
|
| NDAA Compliant |
Yes |
|
Image Setting
|
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR |
|
| Analytics |
Region Intrusion, Abandoned Object, Scene Change, Line Crossing, Video Blur, Video Color Cast Detection |
|
| Smart Alarm |
Motion Detection, SD Card Error, SD Card Full |
|
| Region of Interest (ROI) |
Each ROI to be configured separately |
|
| Connection Protocol |
ONVIF |
|
| Hardware |
Reset Yes |
|
| Audio |
1 Ch. Audio In + Built-in Mic* |
|
Local Storage
|
Built-in Micro SD card slot up to 256GB |
|
| Remote Viewing |
VMS / Web Browswer / iOS & Android Apps
Supported Browsers Internet Explorer (IE) – Plug-in Required, Edge in IE Mode |
|
| Weather Resistance |
IP67 |
|
| Power Input |
12VDC / PoE |
|
| Power Consumption (12VDC) |
350mA (LEDs Off) / 800mA (LEDs On) |
|
| Power Consumption (PoE) |
<8.5W |
|
| Working Environment |
-22° ~140°F (-30°~60°C) / < 95% Humidity |
|
| Weight Net (Shipping) |
24.69oz / 1.54lb / 700g (29.98oz / 1.87lb / 850g) |
|
Dimensions
|
Dia × H 4.30 × 5.15” [109 × 131mm] |
|
| Note |
*Please research local, state and federal laws regarding the implementation of audio surveillance. |
|
