| Image Sensor |
1/ 1.79 “CMOS |
|
| Image Size |
2688 × 1520 |
|
| Lens |
2.8 mm@F1.0, H.FoV: 112°;V.FoV:61°; D.FoV:133° |
|
| Iris Type |
Fixed Iris |
|
| Electronic Shutter |
Auto or manual mode; manual mode: 1 / 2s ~ 1 / 100000 s |
|
| AE Enhancement |
Backlight Control (BLC), Highlight Ccontrol (HLC), Defog, Digital Wide Dynamic Range (D-WDR) |
|
| 3D DNR |
XD-DNR (3D-DNR & 2D-DNR) |
|
| Video Compression |
Main stream: H.265+ / H.265 / H.264+ / H.264 / Sub stream / Third stream: H.265+ / H.265 / H.264+ / H.264/ MJPEG / Fourth stream / Fifth stream: H.265 / H.264 / MJPEG
H.264 Compression
Baseline Profile / Main Profile / High Profile |
|
| Resolution |
4MP (2688×1520), 2K (2560×1440), 3MP(2304×1296),1080P (1920×1080), 720P (1280×720), D1, VGA (640 ×480), CIF, 480×240 |
|
| Stream |
Main Stream
4MP / 2K / 3MP / 1080P (1~30fps)
Sub Stream
1080P / 720P / D1 (1~30fps)
Third Stream
720P / D1 / VGA / CIF / 480×240 (1~30fps)
Fourth Stream
D1/VGA/CIF/480×240 (1~30fps)
Fifth Stream
D1/VGA/CIF/480×240 (1~30fps) |
|
| Bit Rate |
64 Kbps ~ 8 Mbps
Bit Rate Type
VBR/ CBR |
|
| Image Settings |
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Flip, Image Mirror, NR, etc, adjustable through client software or web browser
ROI
Each ROI to be configured separately
|
|
| Audio |
1CH audio input, 1CH audio output, 1CH built-in microphone* |
|
| Storage |
Built-in micro SD card slot supporting up to 1TB / Network remote storage |
|
| Alarm |
1CH alarm input, 1CH alarm output
Smart Event
Line crossing, region intrusion/ entrance/exiting (human/vehicle classification), abandoned/ missing object detection, crowd density detection
Statistics
Target counting by line, heat map
Exception Detection
Scene change, video blur and abnormal color detection |
|
| Face A.I. 4.0 |
Face Detection / Facial Detection, Face Recognition / Facial Recognition, Face Picture Comparison |
|
| Video Meta Data |
Simultaneously captures the human body, motor vehicles, and non-motor vehicles, extracting 13 features from humans, 5 features from motor vehicles, and 1 feature from non-motor vehicles.
|
|
Resolution
|
6MP(3200×1800), 4MP(2688×1520), 1080P(1920×1080 ), 720P(1280×720), D1, VGA(640×480), 480×240, CIF |
|
| DORI Distance |
Detect: 170ft / Observe: 68ft / Recognize: 33ft / Identify: 17ft |
|
| Remote Monitoring |
Web Client / NVR / Vitek Transcendent VMS / Mobile App
Web Browser
IE11(plug-in required) / Chrome 92.0+ / Edge 92.0+ / Firefox 91.0+ / Safari 13.1+
Online Connection
Support simultaneous monitoring for up to 3 users, Support multi-stream real time transmission
Network Protocol
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, FTP, PPPoE, DDNS, SMTP, SNMP, HTTP, 802.1x, UPnP, HTTPS, HTTP POST, QoS
Security
Video encryption, firmware encryption, HTTPs encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP
Network
RJ 45 |
|
| PoE |
Yes, IEEE802.3af |
|
| Interface Protocol |
ONVIF |
|
| Smart Alarm |
Motion detection, sensor alarm, SD card error, SD card full, IP address conflict, cable disconnection |
|
| Additional Features |
Watermark, Video Mask, Heartbeat, Image Distortion Correction, Corridor Pattern |
|
| Angle Adjustment |
Pan: 0°~360°; Tilt:0°~80°; Rotation: 0°~360° |
|
| Power Supply |
DC12V/PoE
Power Consumption
< 5.5W |
|
| Operating Conditions |
-22°F~140°F (-30°C~60°C), Humidity: less than 95 % (non-condensing) |
|
| Installation |
Ceiling mounted or Wall mounted |
|
| Certificate |
CE, FCC |
|
Storage
|
Built-in micro SD card slot (up to 256GB) |
|
| Environmental Protection |
Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006) |
|
Remote Monitoring
|
Web browser / Transcendent NVR / VMS / Mobile App
|
|
| Dimensions (mm) |
5.15” × 4.30” (130.8mm × 109.2mm) |
|
| Weight (net) |
24.70 oz / 1.54 lbs / 700g |
|
| Note |
*Please research local, state, and federal law regarding the implementation and use of audio surveillance |
|
|
|
