Video Input / Resolution
|
32 IP Ch. up to 12 MP: 12/8/6/5/4/3MP/1080P/1280×1024/960P/720P
|
|
Main Monitor Output
|
(HDMI1, HDMI 2, VGA) HDMI 1: 3840×2160 @60fps/30fps, 1080P/1280×1024/1024×768,
HDMI 2: 1920×1080/1280×1024/1024×768, VGA: 1920×1080/1280×1024/1024×768
|
|
Multi-Screen Display
|
Main Output: 1/4/6/8/9/13/16/25/32/36 (Live View), AUX Output: 1/4/6/8/9 (Live View), Max. 32 + 9Ch. Local View
|
|
Multi Operation Pentaplex:
|
Live Display / Record / Playback / Backup / Remote Access
|
|
| Recording Compression |
H.265S / H.265+ / H.265 / H.264
|
|
OS Embedded
|
Linux
|
|
| Recording Resolution |
640fps @ 12MP (20fps per channel), 960 fps =8MP (30fps per channel)
|
|
| Audio over IP |
Inputs 32 (Camera Dependent)
|
|
2-Way Audio, Local Audio In/Out
|
YES, IN: RCA × 1Ch. / OUT: RCA × 1Ch. G.711 (U/A Compression)
|
|
Encode
|
CBR / VBR
|
|
| Recording Modes |
Manual / Timer / Motion / Sensor / Alarm / AI
|
|
| File Management |
Reserving time, Redundancy, Dual Stream Recording
|
|
Local Playback
|
16Ch.
|
|
Gen. IV Advanced Analytics [Camera Dependent]
|
Regional Entrance/Exit, Line Crossing, Target Counting [All by Human/Motor Vehicle Classification] Face Detection [FD], Object Abandoned/Missing, Video Blur, Color Cast, Abnormal Video + License Plate Recognition & Fisheye Dewarping [WEB & APP]
|
|
Face Detection
|
32Ch., 32 Libraries (10,000 Face pics), 18 pics/sec Computing, Search by Pic, Add/Modify/Delete/Search Pics, Add pics w/ App, Web, Ext. Import, Supports Allow/Block Lists and Stranger Match Alarm, Track Display on Map, Bar Graph Stats by Time Period
|
|
| License Plate Recognition |
Supports Overview and Cut-Out of Plate, 10,000 Plate Database, 0-75mph (120kmph) Capture Speed (Installation Dependent)
|
|
| 360° Camera De-Warping |
Multiple Views include 360° Overview, Quad, Overview + 3 Views, and Single View [WEB & APP]
|
|
| Search |
Time Sliced Image Search, Time/Calendar Search, Event (Motion, External Alarm), Tag Search
|
|
| Smart Search |
Highlighted Color to Display Certain Time Periods – Colors Refer to Different Recorded Events
|
|
| Alarm Modes |
Sensor, Motion, Video loss, IP conflict, Disk Error, Illegal access, Network Disconnection, Smart Events
|
|
Alarm In/Output & Triggering
|
16Ch. / 4Ch. / Record, Snap, Alarm out, E-mail
|
|
Network Interface
|
RJ45 10 / 100 / 1000 Mbps × 2
|
|
| Total Bandwidth |
192Mbps Incoming / 192Mbps Outgoing [384Mbps Total]
|
|
| Dual-stream Individual Network Video |
Stream and local recording stream, set separately
|
|
| Network Protocols |
TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, RTSP, HTTP, HTTPS, 802.1x, SNMP, ONVIF
|
|
| Remote Viewing |
VMS / Web Browser / Mobile Platforms [iOS, Android]
|
|
Backup
|
Network, U Disk, USB Mobile HDD
|
|
SATA
|
HDD SATA × 8, Max 12TB each (96TB Total)
|
|
USB
|
USB 3.0 × 1, USB 2.0 × 2
|
|
| RS485 |
RS485 (Full-Duplex), Connect to PTZ
|
|
PTZ Protocol, Support
|
Through Network or RS485 (Pelco D / Pelco P), PTZ Preset and Auto Cruise, up to 255 Presets and 8 Cruises
|
|
| Power Consumption / Supply |
<30W (No HDD), ATX300W (PoE)
|
|
| Working Environment |
14ºF~122ºF (-10º~50ºC) / 10~90% RH
|
|
| Dimensions (W×D×H) |
17.52 × 17.17 × 3.54” (445 × 436 × 90mm)
|
|
| Weight Net |
12.57 lbs (5.7kg), Gross: 16.13lbs (7.4kg)
|
|
|
|
