32 CH 2MP/5MP Lite 5-IN-1 DVR 8xSATA VT
32 CH 2MP/5MP Lite 5-IN-1 DVR 8xSATA VT
Item #
DVT32V5
Brand
Vitek
MFG Part No
VT-TTR1620
Model
VT-TR2HA3280

Color
Black
Warranty
3 Year /1 Year OTC /2 Year MFG
Condition
Retail Box
If out of stock
3 to 5 Days
Product Description

The Ultra Versatile and User friendly Transcendent High Definition 5-in-1 Analog (Coax Based) Digital Recorders support Recording and Playback of TVI/AHD format cameras up to 5MP (Lite Mode) and CVI up to 4MP (Lite Mode) and offer H.265 Compression. Although they are DVRs in nature, they also offer maximum IP channel support in full Hybrid Mode. These recorders share the same client, CMS and mobile applications as the Transcendent NVRs. Camera options include fixed, and Varifocal Motorized Auto Focus with COC and vandal/weather resistant models. Control Drivers are available for various Automation Systems

Specifications

• Video Input 32 Channels HD-TVI / AHD / CVI / CVBS Analog BNC Inputs Supporting up to 5MP Lite
• IP Camera Support 8 IP Cameras (5MP @ 30fps Max)
•  Compression H.265 High profile
• Recording (5MP Lite) 320fps: 10fps per channel
• Recording (4MP Lite / 1080P) 480fps: 15fps per channel
•  Recording (1080P Lite) / (720P) 960fps: 30fps per channel
•  Local Playback 16 CH
•  OS Embedded Linux
• Video Output 1 x HDMI (1080p) / 1 x VGA (1080p) / 1 x BNC Spot (Analog)
• Multi Operation Pentaplex: Live Display / Record / Playback / Backup / Remote Access
• Audio Input: RCA x 16 / Output: RCA x 1
• Two-Way Audio YES
• Bit Rate 32Kbps ~ 5Mbps
• Encode VBR / CBR
• Quality Levels 6 level
• Search Time Sliced, Time, Event, Tag Management
• Function Play, Pause, FF ,FB, Shutter Control, Jog, Digital zoom
•  Alarm In/Out 16 Alarm inputs / 4 Alarm Output
• Alarm Modes Sensor, Motion, Video loss
• Alarm Triggering Record, PTZ move, Relay out, E-mail, etc
• Network Interface RJ45 x 1
• Remote Viewing CMS / Web Browser / Mobile Platforms
• Remote Playback 16CH
• Dual-stream Individual Network Video Stream and local recording stream, set separately
• Remote Users 10 users online, dual stream
• RS485 RS485 x2 (for PTZ)
• PTZ Protocol Control over Coax, Pelco D / Pelco P
• Network Protocols TCP/IP, UDP, DHCP, DNS, PPPOE, DDNS, SMTP, RTSP, HTTP
• SATA HDD Up to 80TB (1 x 10TB) + E-SATA x 1
• USB 2 x USB 2.0
• Accessories Remote controller, SATA cable, USB mouse
• Power Consumption = 30W (Without HDD)
•  Power Supply ATX 250W
• Dimensions (WxHxD) 16.93” x 3.54” x 17.72” (430 x 90 x 450mm)

If you can't find what you're looking for here, Please contact your sales representative
