| Camera Features |
Image Sensor
1/3.1" Progressive CMOS
Resolution
SD:1280 x 720
HD: 1920 x 1080
Lens Type
Fixed-focal
Focal Length
f = 2.8 mm
Aperture
F2.0
Iris
Fixed iris
Field of View
116° (Horizontal)
65° (Vertical)
140° (Diagonal)
Camera Movement
Pan: ±175° Tilt: -10°~75°
Shutter Speed
1/5 sec. to 1/32,000 sec.
Day/Night
Yes
IR Cut Filter
Yes
IR Range
30 meters
WDR Technology
WDR Enhanced
Minimum Illumination
0.08 lux @ F2.0 (Color)
<0.005 lux @ F2.0 (B/W)
0 lux with IR illumination on
Onboard Storage
MicroSD/SDHC/SDXC card slot
(Built-in 128GB industrial SD Card) |
|
| Standard Video Settings |
Frame Rate
15FPS
Video Streaming Settings
HD Video 1920 x 1080@15fps 600Kbps upload
SD Video 1280 x 720@15fps 200Kbps upload |
|
| Standard Audio Settings |
Frame Rate
15FPS
Video Streaming Settings
HD Video 1920 x 1080@15fps 600Kbps upload
SD Video 1280 x 720@15fps 200Kbps upload
Standard Audio Settings
Audio
One-way Audio
Interface
Built-in microphone
Effective Range
5 meters |
|
| Power and Network |
Power Input
IEEE 802.3af Class 0 PoE, DC 12V
(Simultaneous Power Redundancy Supported)
Power Consumption
PoE:
Max. 6.49W/4W (IR on/off)
DC 12V:
Max. 5.1W/3.4W (IR on/off)
Connectivity
RJ-45 cable connector for 10/100 Mbps PoE network connection
Protocols
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, NTP, RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Users
Up to 4 clients
*Live viewing for 4 clients
*live viewing up to 2 clients and playback 2 clients)
Security
Secure boot
HTTPS/TLS encryption
Video encryption
Interface
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
|
| General |
Operating Temperature
Starting Temperature:
-30°C ~ 50°C (-22°F ~ 122°F)
Working Temperature:
-30°C ~ 55°C (-22°F ~ 131°F) (IR off)
-30°C ~ 50°C (-22°F ~ 122°F) (IR on)
Humidity
95% RH (non-condensing)
Certifications
EMC: CE (EN55032 Class B,EN55035), FCC (FCC Part 15 Subpart B Class B), ICES-003 issue 7,RCM (AS/NZS CISPR 32 Class B), VCCI (VCCI-CISPR 32 Class B); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 62471,IEC/EN 60950-22); Environment: IK10 (IEC 62262), IP66(IEC 60529)
Warranty
10 years
Included Accessories
Quick installation guide, alignment sticker, screw pack, cable gland, dessicant bag |
|
| Mechanical |
Weight
465 g
Dimensions
Ø 110x85 mm
Body
Plastic upper cover , Metal bottom |
|
| AI Analytics |
Audio Detection
Yes
Tampering Detection
Yes
People Analytics
Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Vehicle Analytics
Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Object Analytics
Unattended object detection, Missing object detection
|
