2MP 2.8mm WDR+ Bullet Vortex

Item #

CIB20VO

Brand

Vortex

Model

IB639-1Y

Color

White

Warranty

10 Year's / 30 Day OTC

Condition

Retail Box

If out of stock

3 to 5 Days

Add On Products

4TB WD Purple SATA6 5400 RPM 256MB

HDDV40T1

6TB WD Purple SATA6 Intellipower 256M

HDDV60TW6

8TB WD Purple SATA6 5640RPM 256MB

HDDV85TW

10TB WD Purple Pro SATA 256MB

HDDVX10T3W

12TB WD Purple Pro SATA6 7200RPM 256MB

HDDVX12TW1

Product Description

Essential Series
2 MP
Fixed Lens, 2.8mm
30M IR
WDR Enhanced
IP66/IK10
FCC/CE/UL/NDAA/TAA


Camera Features	Camera Features Image Sensor 1/3.1" Progressive CMOS Resolution SD:1280 x 720 HD: 1920 x 1080 Lens Type Fixed-focal Focal Length f = 2.8 mm Aperture F2.0 Iris Fixed iris Field of View 116° (Horizontal) 65° (Vertical) 140° (Diagonal) Camera Movement Tilt: 90° Rotate:180° Shutter Speed 1/5 sec. to 1/32,000 sec. Day/Night Yes IR Cut Filter Yes IR Range 30 meters WDR Technology WDR Enhanced Minimum Illumination 0.08 lux @ F2.0 (Color) <0.005 lux @ F2.0 (B/W) 0 lux with IR illumination on Onboard Storage MicroSD/SDHC/SDXC card slot (Built-in 128GB industrial SD Card)

Standard Video Settings	Frame Rate 15FPS Video Streaming Settings HD Video 1920 x 1080@15fps 600Kbps upload SD Video 1280 x 720@15fps 200Kbps upload

Power and Network	Power Input IEEE 802.3af Class 0 PoE, DC 12V (Simultaneous Power Redundancy Supported) Power Consumption PoE: Max. 6.49W/4W (IR on/off) DC 12V: Max. 5.1W/3.4W (IR on/off) Connectivity RJ-45 cable connector for 10/100 Mbps PoE network connection Protocols WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, NTP, RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP Users Up to 4 clients Live viewing for 4 clients live viewing up to 2 clients and playback 2 clients) Security Secure boot HTTPS/TLS encryption Video encryption Interface 10 Base-T/100 Base-TX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.

General	Operating Temperature Starting Temperature: -30°C ~ 50°C (-22°F ~ 122°F) Working Temperature: -30°C ~ 55°C (-22°F ~ 131°F) (IR off) -30°C ~ 50°C (-22°F ~ 122°F) (IR on) Humidity 95% RH (non-condensing) Certifications EMC: CE (EN55032 Class B,EN55035), FCC (FCC Part 15 Subpart B Class B), ICES-003 issue 7,RCM (AS/NZS CISPR 32 Class B), VCCI (VCCI-CISPR 32 Class B); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 62471,IEC/EN 60950-22); Environment: IK10 (IEC 62262), IP66(IEC 60529) Warranty 10 years Included Accessories Quick installation guide, alignment sticker, screw pack, cable gland

General	Weight 671 g Dimensions Ø 91.1 x 181.5 mm Body Metal

Mechanical	Mechanical Weight 605 g Dimensions Ø 129 x 94 mm Body Plastic

AI Analytics	Tampering Detection Yes People Analytics Intrusion detection, Line crossing detection, Loitering detection, Scene Search Vehicle Analytics Intrusion detection, Line crossing detection, Loitering detection, Scene Search Object Analytics Unattended object detection, Missing object detection
