| Video Input / Resolution |
16 IP Channels up to 8 MegaPixel [4K] 8/6/5/4/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF |
|
| Main Monitor Output |
HDMI × 1: 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA × 1: 1920 × 1080 / 1280 × 1024 / 1024 × 760 |
|
Multi Operation
|
Pentaplex: Live Disp./Record/Playback/Backup/Remote Access |
|
| Recording Compression |
H.265S / H.265+ / H.265 / H.264 |
|
| OS Embedded |
Linux |
|
| Recording |
8/6/5/4/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF@480fps |
|
| Audio |
16 Ch. IPC Audio In., 2-Way: 1 × RCA, Local O/P: 1 × RCA |
|
| Audio Compression |
G.711(U/A) |
|
| Recording Stream |
Dual Stream Recording |
|
| Recording Modes |
Manual, Timer, Motion, Sensor, Analytics |
|
Simultaneous Playback
|
Max. 16 Ch. |
|
| Playback Search |
Time Slice / Time / Event / Tag Search / Smart Search |
|
| Smart Search |
Highlighted Color Displays the Recording in a Certain Time Period, Different Colors Refer to Dif. Events |
|
| Playback Function |
Play, Pause, Fast Forward / Back, Digital Zoom, Smart Events |
|
| Alarm Modes |
Manual, Sensor, Motion, Exception, Smart Events |
|
| Alarm Linkage |
Record, PTZ, Cruise, Alarm out, Pop-up Window, Email, Buzzer, App Push |
|
| Alarm Input / Output |
Supports IP Camera Input / Output |
|
| Alarm Triggering |
Record, Snapshot, Buzzer, Preset, E-mail |
|
| VCA (Video Content Analytics) |
Object Missing, Region Intrusion, Tripwire, Exception |
|
| Other Features |
License Plate Recognition, Human / Vehicle Classification |
|
| POS Information |
Overlay YES – On Live View and Playback |
|
| Network Protocol |
DHCP, DNS, PPPoE |
|
| Network Bandwidth |
96Mbps Incoming / 96Mbps Outgoing |
|
PoE Standard
|
IEEE802.3af |
|
PoE Port
|
RJ45 100M × 16 |
|
Mobile Device
|
iOS, Android |
|
| SATA HDD Storage |
SATA2.0/3.0 × 2 (Max 24TB) |
|
Backup
|
(Network) / Local YES / U Disk, USB Mobile HDD |
|
| USB |
USB 2.0 × 2 (1 Front + 1 Rear) |
|
| Remote Control |
Optional |
|
| Power Consumption/ Supply |
< 10W (Without HDD) / DC 48V / 4A |
|
| PoE Output Power |
= 150W |
|
| Working Environment |
14°~122°F @ 10% ~ 90% RH |
|
| Dimensions (W × D × H) |
14.96 × 10.55 × 1.77” / 380 × 268 × 45mm |
|
| Rack Mountable |
YES (Includes Rack Ears) |
|
| Weight (Net / Shipping) |
3.92 / 7.94lbs (1.78 / 3.6kg) |
